CK6130 Flat bed horizontal CNC lathe
Features
1.Adatable to various control systme such as GSK, KND, Siemens, Fauc,
2. Different appearance shapes such as squre, round and so on.
3. Steay integra casting iron foot
|
Specifications |
CK6130X450 |
|
Machining capacity |
|
|
Max.swing over bed |
360mm |
|
Max.swing over cross slide |
150mm |
|
Max.length of workpiece |
450mm |
|
Width of bed |
252mm |
|
Spindle |
|
|
Spindle speed range |
150-2500rpm |
|
spindle bore |
40mm |
|
spindle nose |
A2-5 |
|
Taper of spindle bore |
MT5 |
|
Chuck diameter |
160mm |
|
Slide stroke |
|
|
X-axis travel |
300mm |
|
Z-axis travel |
450mm |
|
X-axis rapid moving |
6m/min |
|
z-axis rapid moving |
8m/min |
|
Turret |
|
|
Tool station number |
4 or 6 |
|
Max.section of tool |
20x20mm, 16x16mm |
|
Tailstock sleeve |
|
|
External diameter |
50mm |
|
Max.travel |
110mm |
|
Taper of bore |
MT4 |
|
Motor |
|
|
Main motor power |
4KW |
|
Coolant pump power |
120W |
|
Machine dimension |
|
|
Overall dimension |
1700X1070X1600mm |
|
Packing size |
1780X1200X1900mm |
|
Net weight |
1000kg |
|
Gross weight |
1200kg |
Standard accessories :
intergal cast iron stand
conventianl main motor
3-jaw chuck
optional accessories:
variable frequency main motor
servo main motor
spindle unit
hydraulic chuck & tailstock
pneumatic chuck & tailstock
6 postition electric turret
tool array
spring collect
power head
robot arm
automatic bar-feeder
