Spindle speed (rpm)

8000

Spindle servo motor power(KW)

7.5

Feed motor

X / Y / Z axis (Nm)

X/10  Y/10 /Z15

stroke

X-axis travel (mm)

950

Y-axis travel (mm)

500

Z axis travel (mm)

500

Distance from spindle end to table surface (mm)

150-650

Distance from spindle center to column guide surface (mm)

500

table

Table size(mm)

1000X500

Number/width/distance of T-slot(mm)

18-3-125

Worktable bearing weight (Kg)

700

Automatic feed

Rapid feed speed(X.Y.Z) (m/min)

24/24/20

Lead screw

Diameter / pitch (XYZ) (mm)

40/12

Rail form

Roller linear guide

X/35.Y/35 Z/35 Roller

Precision

Positioning accuracy(mm)

0.008

RepeatPositioning accuracy (mm)

0.005/300

system

SIEMENS808-151

GSK980MDI

Tool magazine

BT40-T24

Air force source (pressure / volume) (Mpa)

0.6

Protection

Full protection

Cooling / lubricating

High-pressure water pump (two water and one gas)/ Electronic timed forced lubrication

Overall dimension(mm)

2650X2300X2650

Machine weight(kg)

4500
