Item
|
C6240K*1000
|
|
Max.swing over bed
|
400mm
|
|
Max.swing over cross slide
|
210mm
|
|
Max.swing in gap
|
508mm
|
|
Max.length of workpiece
|
1000mm
|
|
Width of bed
|
260mm
|
|
Spindle speed range
|
(12 changes)40-1800rpm
|
|
Spindle bore
|
φ40mm or φ51mm
|
|
Spindle nose
|
D4 or D5
|
|
Taper of spindle Bore
|
MT5 or MT6
|
|
Center height
|
200mm
|
|
Threads metric pitches
|
0.4-7mm/37kinds(Metric lathe)
0.45-7.5mm/22kinds(inch lathe)
|
|
Threads imperial pitches
|
4-56TPI/28kinds(Metric lathe)
4-112TP/40kinds(inch lathe)
|
|
Compound rest travel
|
90mm
|
|
Cross slide travel
|
210mm
|
|
Max.section of tool
|
16*16mm
|
|
Longitudinal feeds range
|
0.043-0.653mm/rev/40kinds(Metric lathe) 0.0012-0.0294inch/rev/36kinds(inch lathe)
|
|
Cross feeds range
|
0.024-0.359mm/rev/39kinds
|
|
External diameter
|
45mm
|
|
Max.travel
|
110mm
|
|
Taper of bore
|
MT3
|
|
Main motor power
|
2.2kw
|
|
Coolant pump power
|
40w
|
|
Packing size(L*W*H)
|
1990*760*1410mm
|
|
Net weight
|
1350kg
|
|
Gross weight
|
1550kg
|
