SPECIFICATIONS
|
Unit
|
CQ6280C
|
|
|
Capacity
|
Max swing over bed
|
mm
|
Φ800
|
|
Max swing in gap
|
mm
|
Φ1000
|
|
|
Effective length in gap
|
mm
|
240
|
|
|
Max swing over slide
|
mm
|
Φ560
|
|
|
Max workpiece length
|
mm
|
2000/3000
|
|
|
Spindle
|
Spindle thru-hole
|
mm
|
Φ105
|
|
Spindle nose
|
ISO 702/Ⅱ No.8 cam-lock type
|
||
|
Spindle speed
|
r/min
|
12 step 30-1400
|
|
|
Spindle motor
|
kW
|
7.5
|
|
|
Tailstock
|
Quill dia./travel
|
mm
|
Φ90/150
|
|
Taper of center
|
MT
|
5
|
|
|
Tool post
|
Number of station/
|
4/25X25
|
|
|
Tool section
|
|||
|
Feed
|
Max X-axis travel
|
mm
|
145
|
|
Max Z-axis travel
|
m/min
|
320
|
|
|
X-axis feed
|
mm/r
|
65 sorts 0.063-2.52
|
|
|
Z-axis feed Z-axis feed
|
mm/r
|
65 sorts 0.027-1.07
|
|
|
Metric thread
|
mm
|
22 sorts 1-14
|
|
|
Inch thread
|
t.p.i
|
25 sorts 28-2
|
|
|
Module thread
|
πmm
|
18 sorts 0.5-7
|
|
|
DP thread
|
t.p.i. π
|
24 sorts 56-4
|
|
|
Others
|
Coolant pump motor
|
kW
|
0.06
|
|
Machine length
|
mm
|
3365/4365
|
|
|
Machine width
|
mm
|
1340
|
|
|
Machine height
|
mm
|
1490
|
|
|
Machine weight
|
kg
|
3000/3200
|
|
